A High Performance Fuel Efficient 4 Stroke Diesel Engine
Combustion System: Direct injection
Type Single-cylinder, Vertical 4-stroke air cooled diesel engine
Compression Ratio 20 : 1
Maximum Output 6.5kW (8.8hp) @3000rpm; 7.1kW (9.6hp) @3600rpm
Continuous Output 5.7kW (7.7hp) @3000rpm; 6.3kW (8.6hp) @3600rpm
Power Take Off Crankshaft
Revolution Direction Counterclockwise (Viewed from output shaft)
Cooling System Forced air by flywheel fan
Lubricating System Forced lubrication and splash lubrication
Fuel Consumption 312 ml/kW.h @3000rpm; 318 ml/kW.h @3600rpm
Additional Information
| Engine Power (Hp) | 10 | |
|---|---|---|
| Engine Displacement (CC) | 418 | |
| Bore and Stroke (mm) | 86 x 72 | |
| Cooling | Air Cooled | |
| Oil Capacity (CC) | 1600 | |
| Fuel Tank Size (L) | 5.5 | |
| Starting | Electric | |
| Shaft Type | 3/4" Thread | |
| Shaft Length (mm) | 58 | |
| Fuel Type | Diesel | |
| Weight (kg) | 50 | |
| Dimensions (cm) | 60L x 50W x 50H |
