Type Single-cylinder, Vertical 4-stroke air cooled diesel engine
Compression Ratio 20.5 : 1
Maximum Output 8.0kW (11.0hp) @3000rpm; 8.5kW (11.6hp) @3600rpm
Continuous Output 7.0kW (9.5hp) @3000rpm; 7.5kW (10.2hp) @3600rpm
Power Take Off Crankshaft
Revolution Direction Counterclockwise (Viewed from output shaft)
Cooling System Forced air by flywheel fan
Lubricating System Forced lubrication and splash lubrication
Fuel Consumption 288 ml/kW.h @3000rpm; 303 ml/kW.h @3600rpm
Additional Information
| Engine Power (Hp) | 11 | |
|---|---|---|
| Engine Displacement (CC) | 474 | |
| Bore and Stroke (mm) | 88 x 78 | |
| Cooling | Air Cooled | |
| Oil Capacity (CC) | 1600 | |
| Fuel Tank Size (L) | 5.5 | |
| Starting | Both Electric and Recoil | |
| Shaft Type | 1" Keyway | |
| Shaft Length (mm) | 72 | |
| Weight (kg) | 83 | |
| Dimensions (cm) | 52L x 66W x 74H |
