Type: Single-cylinder, vertical, 4-stroke HL170FAE K1 Engine
Combustion System: Direct injection
Lightweight And Compact Design
Easy And Fast Start
Compression Ratio 20.5 : 1
Maximum Output 2.8kW (3.8hp) @3000rpm; 3.1kW (4.2hp) @3600rpm
Continuous Output 2.5kW (3.4hp) @3000rpm; 2.8kW (3.8hp) @3600rpm
Power Take Off Crankshaft
Revolution Direction Counterclockwise (Viewed from output shaft)
Cooling System Forced air by flywheel fan
Lubricating System Forced lubrication and splash lubrication
Starting System Recoil Start
Fuel Consumption 341 ml/kW.h @3000rpm; 347 ml/kW.h @3600rpm
Additional Information
| Engine Power (Hp) | 4 | |
|---|---|---|
| Engine Displacement (CC) | 219 | |
| Bore and Stroke (mm) | 70 x 57 | |
| Cooling | Air Cooled | |
| Oil Capacity (CC) | 800 | |
| Fuel Tank Size (L) | 2.5 | |
| Starting | Both Electric and Recoil | |
| Shaft Type | 3/4" Keyway | |
| Shaft Length (mm) | 58 | |
| Fuel Type | Diesel | |
| Weight (kg) | 34 | |
| Dimensions (cm) | 36L x 43W x 56H |
